SMEC
MCV 6700

Type: Vertical machining center Vertical

Brand: SMEC

Model: MCV 6700

C.N.C: Fanuc 0iTF PLUS

Request a quote

Vertical machining center SMEC MCV 6700

Vertical machining center SMEC MCV 6700

Vertical machining center SMEC MCV 6700

Vertical machining center SMEC MCV 6700

Vertical machining center SMEC MCV 6700

Vertical machining center SMEC MCV 6700

Vertical machining center SMEC MCV 6700

Technical information

Table

Table dimensions: 1700x660 mm
Max table load: 1300 kg

Turning capacity

Longitudinal X-travel: 1600 mm
Cross Y-travel: 670 mm
Vertical Z-travel: 520 mm

Spindle

Spindle nose: 40 ISO
Spindle speed: 12000 giri/min.
Motor power: 11 - 15 Kw

Feed rates

Rapid feedrate axis X,Y,Z: 36000/36000/30000 mm/min

Tool magazine

Tools holder: 30 nr.

Table mm. : 1700x660

X,Y,Z travels mm. : 1600x670x520

Rpm : 12.000

Motor power Kw : 11-15

ISO : 40

Tools : 30
