WELE
UG 550/800
Type: Vertical machining center 5 axes
Brand: WELE
Model: UG 550/800
C.N.C: Heidenhain TNC i530
Watch the video
Technical information
Table
- Table dimensions: 550x550/800x800 mm
Turning capacity
- Longitudinal X-travel: 550/800 mm
- Cross Y-travel: 700/950 mm
- Vertical Z-travel: 500/650 mm
Spindle
- Spindle nose: 40 ISO
- Spindle speed: 14.000 giri/min.
- Motor power: 22 - 31 Kw
Tool magazine
- Tools holder: 30 nr.
Table mm. : 550x550/800x800
X,Y,Z travels mm. : 550/800x700/950x500/650
Rpm : 14.000
Motor power Kw : 22 - 31
ISO : 40
Tools : 30
