PALMARY
GU 42 x 60/ 100/ 150/ 200 S/NC

Type: Cylindrical grinder

Brand: PALMARY

Model: GU 42 x 60/ 100/ 150/ 200 S/NC

Request a quote

Technical information

CAPACITY

Distance between centers: 600/ 1000/ 1500/ 2000 mm
Center height: 210 mm
Maximum weight between centers: 150 Kg
Wheel dimensions: 355x50x127 mm
Wheel motor power: 3.7 Kw

Distance between centers : 600/ 1000/ 1500/ 2000 mm

Center height : 210 mm

Max job weight : 150 Kg

Wheel dimensions : 355x50x127 mm

Weight : 2800/ 3400/ 4300/ 6200 Kg
