ARES SEIKI
R4530-5030
Type: Vertical machining center Drilling & tapping center single spindle
Brand: ARES SEIKI
Model: R4530-5030
C.N.C: Fanuc
Technical information
Table
- Table dimensions: 500/550x320 mm
- Max weight allowed: 200 kg
Capacity
- Longitudinal X-travel: 450/500 mm
- Cross Y-travel: 300 mm
- Vertical Z-travel: 300 mm
Spindle
- Spindle nose: 30 ISO
- Spindle speed: 10.000 rpm.
- Motor power: 5.5 Kw
Tool Warehouse
- Tool Stations: 12 no.
Table mm. : 500/550 x 320
X,Y,Z strokes mm. : 450/500 x300x300
RPM : 10.000
Power Kw : 5.5
ISO : 30
Tools : 12
