PALMARY
OCD 42100/ 42150

Type: Cylindrical grinder Cylindrical CNC

Brand: PALMARY

Model: OCD 42100/ 42150

C.N.C: Fanuc Oi - TF

Request a quote

Cylindrical grinder PALMARY OCD 42100/ 42150

Technical information

CAPACITY

Distance between centers: 1000/ 1500 mm
Center height: 210 mm
Maximum grinding diameter: 400 mm
Maximum weight between centers: 150 Kg
Wheel dimensions: 405x50/75x127 mm
Wheel motor power: 3.75 (5.5) Kw

MACHINE DIMENSIONS

Weight: 4500/ 5000 Kg

Distance between centers : 1000/ 1500 mm

Center height : 210 mm

Max job weight : 150 Kg

Wheel dimensions : 405x50/75x127 mm

Weight : 4500/ 5000 Kg
